| Specification | Details |
|---|---|
| Laser Type/Wavelength | Fiber laser, 1,070 nm |
| Average Power | 450 W |
| CW Power | 450 W |
| Peak Pulse Power | 4.5 kW |
| Pulse Energy | 45 J |
| Pulse Duration | 0.2 – 50 ms/CW |
| Pulse Frequency | Single pulse – 100 Hz |
| Welding Spot Ø | 0.2 – 3.0 mm |
| Focusing Objective | 150 mm (further according to lens data sheet) /td> |
| Pulse Shaping | Adjustability of power curve within a laser pulse |
| Display and Operation | Laser parameters set through touchscreen, multifunctional footswitch keyboard or/and AL-DRIVE |
