| Specification | Details |
|---|---|
| Laser Type/Wavelength | Nd:YAG, 1,064 nm |
| Average Power | 100 W |
| Peak Pulse Power | 7 kW |
| Pulse Energy | 80 J |
| Pulse Duration | 0.5–20 ms |
| Pulse Frequency | 0-50 Hz |
| Welding Spot Ø | 0.2-2.0 mm / 0.05-0.5 mm with micro-welding function |
| Focusing Objective | Selectable (straight objective or turn/tilt objective) |
| Pulse Shaping | Adjustability of power curve within a laser pulse |
| Display and Operation | Removable touch display (for laser and motion system) |
